WUXI MAZS MACHINERY SCIENCE & TECHNOLOGY CO., LTD.
| Place of Origin: | China |
|---|---|
| Brand Name: | MAZS |
| Certification: | CE, ISO |
| Minimum Order Quantity: | 1 Set |
| Price: | RMB/USD/EURO |
| Packaging Details: | wooden case, polystyrene foam and other protective materials |
| Delivery Time: | 60 days to 120 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 50 to 60 sets per month |
| Weight: | 2500KG | Max Bending Angle: | 135° |
|---|---|---|---|
| Max Bending Thickness: | 2mm | Control Type: | CNC |
| Max Bending Speed: | 8m/min | Voltage: | 380V |
| Dimension: | 6000*3000*2500mm | Motor Power: | 4.5KW |
| Highlight: | 15 Axis Automatic Panel Bender,Automatic Panel Bender 2000mm,steel plate bender 380V |
||
| Items | Technical Parameters for Panel Bending Center | ||
| MAY-1415 | MAY-2015 | MAY-2515 | |
| Feeding method | Pressing arm | Pressing arm | Pressing arm |
| Positioning method | Y axis double lift automatic positioning tools | Y axis double lift automatic positioning tools | Y axis double lift automatic positioning tools |
| Max. bending speed | 0.2 s/time | 0.2 s/time | 0.2 s/time |
| Max. bending width | 1400mm | 2000mm | 2500mm |
| Max. bending height | 170mm | 170mm | 170mm |
| Rated voltage | 380V | 380V | 380V |
| Total motor power | 40Kw | 77Kw | 79Kw |
| Average power | about 1.9Kw | about 2.5Kw | about 2.9Kw |
| Noise | 50dB | 50dB | 50dB |
| Machine size | 440*190*290cm | 510*265* 330cm | 565* 300* 340cm |
| Total machine weight | about 12t | about 18t | about 23t |
| Max. bending thickness (thicker panel customized) | UST 515N/mm2 304 stainless steel 2.0mm | UST 515N/mm2 304 stainless steel 2.0mm | UST 515N/mm2 304 stainless steel 2.0mm |
| UST 410N/mm2 cold panel 3.0mm | UST 410N/mm2 cold panel 3.0mm | UST 410N/mm2 cold panel 3.0mm | |
| Minimum panel thickness | 0.35mm | 0.35mm | 0.35mm |
| Four sides forming minimum inner size | 160* 210mm | 160* 210mm | 160* 210mm |
| Double sides forming minimum inner size | 160mm | 160mm | 160mm |
| Max. bending size | 1400* 1400mm | 2000*1500mm | 2500*1500mm |
| Axis qty. | standard synchronized 15 axis | standard synchronized 15 axis | standard synchronized 15 axis |
| Power hinge knife | standard | standard | standard |
Packaging and Shipping for Automatic Panel Bender
The Automatic Panel Bender is shipped in a double-walled, shock-resistant corrugated cardboard packaging. The packaging is designed to protect the Panel Bender from any external damage during transit. The package contains all the necessary components and tools for installation and safe operation.
Once the Panel Bender is packed, it is shipped to the customer’s address using reliable courier services. The customer receives a tracking number to track the status of the shipment.
