CNC Automatic Bending Machine 0.2s/Time Speed for High Speed Panel Bending
Basic Properties
Place of Origin:
CHINA
Brand Name:
D.K.HISTRON
Certification:
CE,ISO9001
Model Number:
HC-1600
Trading Properties
Minimum Order Quantity:
1SET
Price:
12000-200000USD
Payment Terms:
T/T
Supply Ability:
20sets/month
Specifications
| Productname: | Panel Bender | Type: | Bending Machine |
| Speed: | 0.2s/time | Flexibility: | High |
| Bendinganglerange: | 0° To 180° | Controlsystem: | CNC (Computer Numerical Control) |
| Precision: | ±0.1mm | Safetyfeatures: | Emergency Stop, Safety Guards |
| Automationlevel: | Fully Automated | Powersupply: | Electric |
| High Light: | ±0.1mm Precision Panel Bender,Fully Automated CNC Bending Machine,0.2s/time Speed Automatic Bending Machine |
||
Product Description
Advanced Economic Automatic Panel Bender
Precision CNC bending solutions available in 1400mm, 2000mm, 2500mm, and 3000mm configurations for industrial manufacturing applications.
Key Features
Pressure arm feeding system for high versatility and material handling
Customizable auxiliary folding knife and power hinge knife configurations
Customized processing of workpiece bending height for specialized applications
Customized presser foot lifting function for enhanced operational flexibility
High-speed motors for improved processing efficiency and productivity
Technical Parameters
| Model | HC-1600 | HC-1600P |
| Feeding structure | Pressure arm type | Pressure arm type |
| Minimum internal dimensions for quadrilateral forming | 180mmx280mm | 180mmx280mm |
| Bending height | 170mm(customizable) | 170mm(customizable) |
| Average power | About 1.9KW | About 2.0KW |
| User operating environment | Operation system above Win7 | Operation system above Win7 |
| Maximum bending thickness | Cold plate 1.5mm | Cold plate 2.0mm |
| 304 stainlesss steel 1.0mm | 304 stainlesss steel 1.5mm | |
| Number of axles | 13 | 13 |
Advanced Control System
The bending center control system employs a top-level computer numerical control (CNC) system integrated with motion control cards. The CNC system features an intuitive human-machine interface and supports graphical programming. With exceptional position calculation capabilities, it significantly enhances production efficiency and precision in automated manufacturing.
User-Friendly Operation Interface
The interface is simple, easy to learn, with excellent human-computer interaction designed for efficient operation and minimal training requirements.
Industrial Applications
Custom height versions serve specialized applications including deep-drawn components, tall-flange enclosures, architectural features requiring extended bends, medical equipment with unusual geometries, and custom fabrication projects where standard height is insufficient.
Technical Specifications
| Sheet Thickness Range | 0.35mm to 3mm |
| Bending Accuracy | High precision bending capabilities |
| Operation Type | Automated with effortless functionality |
| Construction Materials | Durable brass/copper, stainless steel, carbon steel, or aluminum |
| Application Scope | Wide range of industries with multifunctional capabilities |
Shipping & Delivery Information
| Delivery Time | 60 working days after deposit confirmation |
| Transportation Methods | Sea freight or land transport available, handled by professional freight companies |
| Quality Assurance | Full function testing conducted before shipment |
| Export Documentation | Commercial invoice, packing list, certificate of origin, and other required documents |
Frequently Asked Questions
Can you arrange samples for me?
Of course, we provide free samples according to customer requirements.
What is the warranty period for the machine?
The warranty period for the machine is one year. Lifetime maintenance and upgrade services are provided after the warranty period.
Are all the machines standard?
No, customization is available. We can manufacture non-standard machines according to customer requirements.
What types of sheet materials can your machine bend?
Typically, carbon sheet, aluminum sheet, stainless steel sheet, and galvanized sheet are available for processing.
