WUXI MAZS MACHINERY SCIENCE & TECHNOLOGY CO., LTD.
| Place of Origin: | China |
|---|---|
| Brand Name: | MAZS |
| Certification: | CE, ISO |
| Model Number: | MAY-2515A |
| Minimum Order Quantity: | 1 Set |
| Price: | RMB/USD/EURO |
| Packaging Details: | Wooden case, polystyrene foam and other protective materials suitable for sea transportation |
| Delivery Time: | 60 days to 120 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 50 to 60 sets per month |
| Feeding Method: | Pressing Arm | Waterproof Rating: | IPX-8 |
|---|---|---|---|
| Positioning Method: | Y Axis Double Lift Automatic Positioning Tools | Axis QTY: | Standard Synchronized 15 Axis |
| Suitable Material: | Stainless Steel, Aluminum Panel, Cold Panel And Other Metal Materials | Work Table Structure: | Brush |
| System Minimum Accuracy: | 0.001mm | Warranty: | 1 Year |
| Highlight: | 3MM metal bending equipment,5650 X 3000 X 3400mm metal bending equipment,industrial sheet metal bender 0.2 Sec/Time |
||
| Items | Technical Parameters |
|---|---|
| Two sides forming minimum inner size | 160mm |
| Rated Voltage | 380V |
| Motor Power | 79KW |
| Average Power | Approx. 2.9KW |
| Model | MAY-2515A |
| Axis QTY | Standard Synchronized 15 Axis |
| Machine Size | 5650*3000*3400mm |
| Max. Bending Thickness | 304 Stainless Steel 2.0mm; Cold Panel 3.0mm |
| Power Hinge Knife | Standard |
| Max Bending Height | 170mm |
| Product Type | CNC sheet metal folding machine, Automatic sheet metal bending center, Sheet metal forming machine |
Packaging and Shipping for Metal Sheet Bending Machine:
- The CNC Bending Machine will be packed in wooden crates or cases.
- The package is designed to protect the machine from humidity and physical damage during transportation.
- The packing will meet international shipping standard.
- The machine can be shipped by air, sea, truck, or train.
